Description
Plummer block housing unit G3..-NPP-B, RIBB sheet metal PB
INA
G310-NPP-B
Self-aligning deep groove ball bearings
⌀50 × 110 × 27 mm
od EUR 163.63z VAT
netto EUR 133.03 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
G310-NPP-B—
EUR 163.63
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)G310-NPP-B#N1>1
EAN4064327887146
Wymiary⌀50 × 110 × 27 mm
Masa980 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
20 parametersIdentification
- Manufacturer
- INA
- Type
- Self-aligning deep groove ball bearings
- Part number (SKU)
- G310-NPP-B#N1>1
- EAN
- 4064327887146
Dimensions
- Bore d
- 50 mm
- Outside diameter D
- 110 mm
- Width B
- 27 mm
- Mass
- 980 g
Load ratings and operation
- Dynamic load rating C
- 66000 N
- Static load rating C₀
- 38000 N
- Sealing
- NPP
Full manufacturer specification9 parameters · expand
- Distance to lubrication hole
- 8.7 mm
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -20.0 °C
- PFAS
- nein
- REACH
- REACH conform
- Rib diameter sealing inner ring
- 64.6 mm
- RoHS
- RoHS compliant
- Sealing
- NPP
- Shape of outer surface
- B
