Description
Radial insert ball bearing E..-KTT-B
INA
E50-KTT-B-L285/70
Radial insert ball bearing
⌀50 × 90 × 49.2 mm
od EUR 60.47z VAT
netto EUR 49.16 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
E50-KTT-B-L285/70—
EUR 60.47
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)E50-KTT-B-L285/70#N15>1
EAN4064327886989
Wymiary⌀50 × 90 × 49.2 mm
Opakowanie15 szt.
Minimum order15 szt.
Masa984 g
Ten towar sprzedawany jest w opakowaniach po 15 szt.
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
26 parametersIdentification
- Manufacturer
- INA
- Type
- Radial insert ball bearing
- Part number (SKU)
- E50-KTT-B-L285/70#N15>1
- EAN
- 4064327886989
Dimensions
- Bore d
- 50 mm
- Outside diameter D
- 90 mm
- Width B
- 49.2 mm
- Mass
- 984 g
Load ratings and operation
- Dynamic load rating C
- 35000 N
- Static load rating C₀
- 23200 N
- Sealing
- KTT
Full manufacturer specification15 parameters · expand
- Calculation factor
- 14.4
- Distance raceway
- 24.6 mm
- Fatigue load limit, radial
- 990.0 N
- Lubricant
- L285/70
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -20.0 °C
- Outside diameter locking collar/locknut
- 69.0 mm
- Outside diameter seal
- 77.3 mm
- PFAS
- nein
- Rib diameter inner ring
- 62.8 mm
- Sealing
- KTT
- Sealing total width
- 26.7 mm
- Shape of outer surface
- B
- Width of flats
- 5.0 mm
- Width, outer ring
- 22.0 mm
