Description
Radial insert ball bearing E..-XL-KRR-B-OSE
INA
E35-XL-KRR-B-L402/70-OSE
Radial insert ball bearing
⌀35 × 72 × 37.7 mm
od EUR 31.57z VAT
netto EUR 25.67 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
E35-XL-KRR-B-L402/70-OSE—
EUR 31.57
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)E35-XL-KRR-B-L402/70-OSE#S21
EAN4064327237354
Wymiary⌀35 × 72 × 37.7 mm
Opakowanie21 szt.
Minimum order21 szt.
Masa400 g
Ten towar sprzedawany jest w opakowaniach po 21 szt.
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
27 parametersIdentification
- Manufacturer
- INA
- Type
- Radial insert ball bearing
- Part number (SKU)
- E35-XL-KRR-B-L402/70-OSE#S21
- EAN
- 4064327237354
Dimensions
- Bore d
- 35 mm
- Outside diameter D
- 72 mm
- Width B
- 37.7 mm
- Mass
- 400 g
Load ratings and operation
- Dynamic load rating C
- 25500 N
- Static load rating C₀
- 15300 N
- Sealing
- KRR
Full manufacturer specification16 parameters · expand
- Calculation factor
- 13.8
- Fatigue load limit, radial
- 800.0 N
- Lubricant
- L402/70
- Marketing category
- XL
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -20.0 °C
- Outside diameter seal
- 60.1 mm
- PFAS
- nein
- REACH
- REACH_YES_115-86-6_597-82-0!
- Rib diameter inner ring
- 46.84 mm
- RoHS
- RoHS compliant
- Sealing
- KRR
- Sealing total width
- 22.5 mm
- Shape of outer surface
- B
- Width, outer ring
- 19.0 mm
- Without locking device
- OSE
