Description
Drawn cup needle roller bearings with closed end BK, to DIN 618/ISO 3245
INA
BK1212-A
Drawn cup needle roller bearing closed end
od EUR 4.67z VAT
netto EUR 3.80 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
BK1212-A—
EUR 4.67
Cheaper in larger quantities
| from 2500 pcs | EUR 3.46 | −9% |
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)BK1212-A#N
EAN4012802436525
Masa10 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
30 parametersIdentification
- Manufacturer
- INA
- Type
- Drawn cup needle roller bearing closed end
- Part number (SKU)
- BK1212-A#N
- EAN
- 4012802436525
Dimensions
- Outside diameter D
- 18 mm
- Mass
- 10 g
Load ratings and operation
- Dynamic load rating C
- 6500 N
- Static load rating C₀
- 7300 N
- Limiting speed
- 20000 1/min
- Sealing
- Without
Full manufacturer specification20 parameters · expand
- Coating
- Without
- Fatigue load limit, radial
- 880.0 N
- Limiting speed for grease lubrication
- 12000.0 1/min
- Lubricant
- Without
- Lubrication hole
- Without
- Minimum chamfer dimension
- 0.8 mm
- Minimum width to base of drawn cup with closed end
- 9.3 mm
- Operating temperature max.
- 140.0 °C
- Operating temperature min.
- -30.0 °C
- PFAS
- nein
- REACH
- REACH conform
- Reference speed
- 15500.0 1/min
- RoHS
- RoHS compliant
- Sealing
- Without
- Sealing ring
- SD12X18X3
- Sealing ring 2
- G12X18X3
- Suitable inner rings IR
- IR8X12X12,5-XL
- Suitable inner rings LR
- LR8X12X12,5
- Under roller diameter
- 12.0 mm
- Width, outer ring
- 12.0 mm
