Description
CONCEPT1, Single-point lubricator (125 cm³, empty)
Schaeffler
ARCALUB-C1-125-REFILLABLE
Automatic lubricator CONCEPT
od EUR 31.18z VAT
netto EUR 25.35 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
ARCALUB-C1-125-REFILLABLE—
EUR 31.18
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)ARCALUB-C1-125-REFILLABLE#N10
EAN4054372535307
Opakowanie10 szt.
Minimum order10 szt.
Masa81 g
Ten towar sprzedawany jest w opakowaniach po 10 szt.
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
23 parametersIdentification
- Manufacturer
- Schaeffler
- Type
- Automatic lubricator CONCEPT
- Part number (SKU)
- ARCALUB-C1-125-REFILLABLE#N10
- EAN
- 4054372535307
Dimensions
- Mass
- 81 g
Full manufacturer specification18 parameters · expand
- Connection thread
- G¼
- Dimensions (mm)
- 117,5 x 53 x 53
- Drive system
- HG
- Functional principle
- Gas drive
- Housing material
- Polyethylenterephthalat (PET)
- Lubricant
- ≤ NLGI 2 (suitability test required)
- Lubricant volume
- V125
- Mounting position
- arbitrary
- Number of lubrication points: direct
- 1
- Number of outlets
- 1.0
- Operating pressure, max.
- 5.0 bar
- Operating temperature, max.
- 55.0 °C
- Operating temperature, min.
- -20.0 °C
- Operating voltage
- —
- PFAS
- nein
- Protection class
- IP68
- REACH
- REACH conform
- RoHS
- RoHS compliant
