Description
Axial deep groove ball bearing 511, single direction, steel sheet metal cage
FAG
51118
Axial deep groove ball bearing
od EUR 37.02z VAT
netto EUR 30.10 · cena detaliczna
51118—
EUR 37.02
Cheaper in larger quantities
| from 50 pcs | EUR 28.59 | −5% |
Last few (2)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)51118#N1
EAN4012801016827
Masa650 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
31 parametersIdentification
- Manufacturer
- FAG
- Type
- Axial deep groove ball bearing
- Part number (SKU)
- 51118#N1
- EAN
- 4012801016827
- Cage
- JP
- Tolerance class
- PN
Dimensions
- Mass
- 650 g
Load ratings and operation
- Dynamic load rating C
- 45500 N
- Static load rating C₀
- 140000 N
- Limiting speed
- 4300 1/min
Full manufacturer specification21 parameters · expand
- Basic dynamic load rating, axial
- 45500.0 N
- Basic static load rating, axial
- 140000.0 N
- Cage
- JP
- Dimensional / heat stabilization
- S0
- Fatigue load limit, axial
- 6300.0 N
- Height
- 22.0 mm
- Inner diameter housing washer
- 92.0 mm
- Inner diameter shaft washer
- 90.0 mm
- Maximum diameter of housing shoulder
- 102.0 mm
- Maximum filled radius
- 1.0 mm
- Minimum chamfer dimension
- 1.0 mm
- Minimum diameter shaft shoulder
- 108.0 mm
- Minimum load factor
- 0.13
- Operating temperature max.
- 150.0 °C
- Operating temperature min.
- -30.0 °C
- Outer diameter housing washer
- 120.0 mm
- Outer diameter shaft washer
- 120.0 mm
- PFAS
- nein
- REACH
- REACH conform
- Reference speed
- 3500.0 1/min
- RoHS
- RoHS compliant
