Description
Spherical roller bearings 222S, split spherical roller bearings, with inch size bearing bore
FAG
222S.203
Spherical Roller Bearing
⌀55.563 × 120 mm
od EUR 1,461.93z VAT
netto EUR 1,188.56 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
222S.203—
EUR 1,461.93
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)222S.203#N1
EAN4012801478519
Wymiary⌀55.563 × 120 mm
Masa2.30 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
35 parametersIdentification
- Manufacturer
- FAG
- Type
- Spherical Roller Bearing
- Part number (SKU)
- 222S.203#N1
- EAN
- 4012801478519
- Cage
- TVPA
Dimensions
- Bore d
- 55.563 mm
- Outside diameter D
- 120 mm
- Mass
- 2.30 kg
- Radial clearance
- CN (Group N)
Load ratings and operation
- Dynamic load rating C
- 136000 N
- Static load rating C₀
- 155000 N
- Limiting speed
- 2850 1/min
Full manufacturer specification23 parameters · expand
- Adapter sleeve
- H313X203
- Bearing designation
- 22213K
- Bore type
- Z
- Cage
- TVPA
- Design
- E1A
- Dynamic axial load factor
- 4.44
- Fatigue load limit, radial
- 15800.0 N
- Housing
- SNV120
- Limiting value of Fa/Fr for the applicability of diff. Values of factors X and Y
- 0.23
- Maximum axial load
- 5400.0 N
- Minimum chamfer dimension
- 1.5 mm
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -30.0 °C
- PFAS
- nein
- Radial internal clearance
- CN (Group N)
- REACH
- REACH conform
- Relubrication feature
- Standard
- RoHS
- RoHS compliant
- Splitted
- S.
- Static axial load factor
- 2.92
- Tightening torque clamping screw
- 9.0 Nm
- Width inner ring
- 55.0 mm
- Width, outer ring
- 31.0 mm
